Wind Turbines
Encoder
Photoelectric encoders for wind turbine ·Generators, ·Slip rings and ·Pitch control
Preface
- Photoelectric encoders for wind turbine generators, slip rings and pitch control.
- Customization is accepted（quantity requirement）, with a two-year quality guarantee, and can be used in extreme weather conditions.
- Can be used as encoder spare parts for Baumer（HOG 10/ HOG 9/OG 8/ HOG 86...）, P+F, Kubler, LEINELIDE(865/ 862/ 861), Thalheim, Hein Lanz, Hohner and other companies.
Key Features
Special rugged housing and High-strength metal disk for high vibration and shock resistance.
9-30VDC, Single power supply, polarity protectionIP66, availble for outdoor use
Advanced high-reliability optical reading system, good performance in electromagnetic compatibility
Overvoltage,overcurrent,surge protection.
Output signals HTL or TTL
Heavy Duty design for high shaft load
Technical Specification
Encoder for Wind Turbines
• Shaft mounting type
Solid shaft
• Body outer diameter
∅115mm
• Shaft diameter/aperture
∅11mm
• Body fixing method
European B10 standard flange
• Maximum speed (mechanical)
6000r/min
• Maximum resolution
2500CPR
• Operating voltage
5V or 10~30V
• Output method
HTL or TTL
• Operating temperature
-40°C~ +85°C
• Protection level
IP66
Product Inquiry
Tell us your project requirements, our engineering team is ready to assist you. Your information will be 100% confidential.
